Vacuum coating machine

ONE TECH line-mounted UV dryer is used for primer and top coat drying. It is used for instant drying of a primer and paint film immediately after painting with UV materials. Five sets of UV lamps can cure all kinds of UV light-cured paints to the semi-dry or completely dry state.

– The body is made of cold-rolled steel sheet, painted with polymer, by cutting and welding;
– The conveyor consists of stainless steel rods with a chain drive. Smooth speed control is provided by a motor with a speed control inverter;
– OSRAM UV lamp. Guaranteed 700 hours of operation in normal conditions;
– Special reflective coating for aluminium alloy can reflect more than 98% of the light source, making the UV light more penetrating.
– The entire machine is controlled by PLC and a touch screen. The light source can be adjusted for bright and faint light. The panel is easy and user-friendly.
– All electrical components are Schneider, Omron and Chint products.

Technical characteristics:

Maximum workpiece width: 350 mm
Workpiece height: 3-90 mm
Minimum workpiece length: 500 mm
Workpiece painting speed: 0.5-40 m/min
Conveyor motor power: 0.4 kW x 1
Fan power: 1.5 kW x 2
Lamp power: 28.4 kW
Power supply: 380 V; 50 Hz
Total power of equipment: 32 kW
External dimensions: L 2,300 mm x W 900 mm x H 2,150 mm

The paintwork material spreading tunnel uses the principle of infrared heating, which has a levelling and defoaming effect on the paint on the product surface and makes the painted surface of the part flatter.

– The body is made of cold-rolled steel sheet, painted with polymer, by cutting and welding;
– Fire-resistant stone wool is used for thermal insulation;
– Heating method: middle IR band lamps;
– The conveyor motor is equipped with a speed control inverter;
– All electrical components are Schneider, Omron and Chint products.

Technical characteristics of the spreading tunnel:

Maximum workpiece width: 350 mm
Workpiece height: 3-150 mm
Minimum workpiece length: 500 mm
Workpiece painting speed: 0.5-40 m/min
Conveyor motor power: 0.75 kW x 1
Heating power: 0.5 kW x 6
Power supply: 380 V; 50 Hz
Total power of equipment: 4 kW
External dimensions: L 4,000 mm x W 750 mm x H 1,200 mm

The grinding machine consists of twelve dual-purpose grinding units. The machine can be equipped with a grinding belt, a grinding wheel, or a polishing wheel.

– Motors of the machine with frequency converters enable a smooth speed control of both the conveyor and the rotation of the grinding wheels/belts;
– The grinding units are equipped with an automatic compensation device with an accuracy of 0.04 mm/time;
– The angle of each group of grinding units can be adjusted from the touch screen control panel

Technical characteristics of the profile grinding machine:

Workpiece width: 20-180 mm
Minimum workpiece length: 500 mm
Work piece thickness range: 3-80 mm
Feed speed: 3-40 m/min
Feed motor power: 0.55 × 11 kW, frequency conversion speed regulation
Grinding unit motor power: 1.5 kW × 12 (special long axis motor)
Number of unit configurations: 12 sets (with automatic compensation of the grinding unit, PLC)
Automatic compensation: 0.04 mm/step
Shaft speed (frequency converter control): 1,900 rpm
Adjustable shaft rotation angle
Shaft size (shaft diameter × length): Ø25.4 × 100 m × 10; Ø25.4 × 150 mm × 2
Grinding wheel size (outer diameter): 200 mm
Suction pipe diameter (dust collection): 100 mm
Working air pressure: 0.2 ~ 0.6 MPa
Power supply: 380 V; 50 Hz
Total power: 24 kW
Overall dimensions: 8,600 × 1,500 × 1,550 mm
Weight: approx. 4.5 t
